ST Bushing P1 14 mm B Dia 1.938 in L
Manufacturer: APPROVED VENDOR
Jahnda Part Number: 2010626
EA
Save 5%
Original price
$39.74
Original price
$39.74
-
Original price
$39.74
Original price
$39.74
Current price
$37.75
$37.75
-
$37.75
Current price
$37.75
Description
Split Taper Bushing Bushing Type Split Taper Bore Bushing Series P1 Bore Diameter 14 mm Length 1.938 in Bolt Circle Diameter 2.44 in Bolt Size Not Applicable System of Measurement Metric Bushing Diameter 1.938 in Fastener Tightening Torque Capacity 192 in-lb Flange Type Solid Flange Width 13/32 in For Shaft Type Keyed Includes (3) Cap Screws Keyway Height 2.4 mm Keyway Width 5 mm Length Less Flange 1.531 in Material Steel Overall Diameter 3 in Taper 3/4 in Per ft
Product Specification
| Characteristic | Value |
|---|---|
| Weight (lb.) | 0.8 lb |
| Items per Unit of Issue | 1 |
| Country of Origin (subject to change) | China |
