Motor 3PH 3/4HP 1800 208-230/460V WD 56C
Manufacturer: U.S. MOTORS
Jahnda Part Number: 30X99N
EA
Description
Three Phase Motor Three Phase Motor Design 3-Phase 3/4 HP No of Speeds 1 Voltage 208-230/460V AC Full Load Amps 2.6-2.4/1.2 A 56 Frame Usable @ 208V Yes 60 Hz Motor Service Factor 1.15 Motor Thermal Protection None Ins. Class F Max Ambient Temp 40 Degrees C NEMA Design B Motor Shaft Rotation CCW Motor Enclosure Design Totally Enclosed Non-Ventilated Motor Mounting Type Face Motor Frame Material Stainless Steel Finish White Epoxy Paint
Product Specification
| Characteristic | Value |
|---|---|
| Weight (lb.) | 35.0 lb |
| Items per Unit of Issue | 1 |
| Country of Origin (subject to change) | Mexico |
