Motor 20HP 3535/2920rpm 256T 60/50Hz 230
Manufacturer: U.S. MOTORS
Jahnda Part Number: 62Z68K
EA
Description
Motor Three Phase Motor Design 3-Phase 20 HP Nameplate RPM 3 535/2 920 No of Speeds 1 Voltage 200V 208V 230V 400V 460V Full Load Amps 46.0/23.0 A 256T Frame Usable @ 208V Yes Usable @ 200V Yes Hz 60/50 Hz Motor Service Factor 1.15 Max Ambient Temp 104 Degrees F Duty Cycle Continuous Ins. Class F NEMA Design B Motor Enclosure Design Totally Enclosed Fan-Cooled Motor Shaft Rotation CW/CCW Motor Mounting Type Horizontal Footed Motor Mounting Position Horizontal
Product Specification
| Characteristic | Value |
|---|---|
| Weight (lb.) | 260.0 lb |
| Items per Unit of Issue | 1 |
| Country of Origin (subject to change) | Mexico |
